IGEN Piston compressed air technology characterized by a high nebulization rate and there for have a relatively short inhalation time and fast treatment.
Powerful Compressor Output: Delivers medication at a faster rate, reducing session time.
Durability and Reliability: Built for extended usage over time without performance drops.
Ease of Maintenance: Designed for easy cleaning and regular upkeep in busy clinical environments.
User-Friendly Design: Simple controls and easy-to-assemble parts for quick operation.
IGEN Compressor Nebulizer Overview
Key Features:
• Oil-Free High-Efficiency Piston Pump: Ensures smooth and reliable operation with minimal maintenance.
• Compact & Portable: Small, round design makes it easy to carry and use anywhere.
• Enhanced Atomization: Produces a large volume of fine mist particles for effective treatment.
• Advanced Filtration: Incorporates a polymer filter to thoroughly clean pollutants from the air.
• Low Noise: Quiet operation ideal for family use and medical units.
• Eco-Friendly: High environmental protection standards ensure safe and sustainable use.
Ideal For:
Perfect for home use, travel, and medical facilities requiring efficient respiratory therapy.
PARAMETER SPECIFICATION
Rated voltage 220V/50Hz
Liter flow range > 6.7lpm
Maximum nebulization rate ≥0.25mL/min
Sound level ≤65db(A)
Particle size 0.5-10um
Mmad 5um
Operation pressure range 9.5-19Psi
Compressor pressure range 22-58Psi
Product size 300*180*110mm
Unit weight 1.5kg
HOW TO USE IGEN NEBULIZER
To use the nebulizer, fill the medication container with the appropriate agent of medication prescribed by your doctor. After completely assembling the device, either take the mouthpiece or place the mask over your mouth and nose, switch the nebulizer on. Then start breathing evenly and deeply until the agent in the medication container is empty. The most effective sitting position during nebulization is sitting upright.
During nebulization, the added agent is the conveyed in the airways. it is reliably transported in to the bronchi or lugs, upper and lower airways. Nebulizer is designed to break down the medication into fine particles that can be easily inhaled. The finer the particles, the deeper the particles can enter into the lower airways and lungs
Technical data
Liter flow range- 6.7 L/min
Average nebulization rate -0.25 ml/min
Sound level-65 Db (A)
Partial size-0.5-10
Operating humidity range -15 to 80 RH
Operation pressure range-9.5 -19 psi
Compressor pressure range-22-58 psi
Product size 300*180*110 mm
Unit weight- 1.5kg
